IBM System x3850 X5 Implementation Guide

Chapter 7. IBM System x3690 X5 353
Figure 7-50 Build process is finished
Preparing the USB key
Follow these steps to create a bootable USB key with the Windows installation image that
was created in “Creating a deployment image” on page 350:
1. Insert your USB key.
18:26:21 - Creating the WinPE x64 ISO...
18:27:07 - The WinPE x64 ISO was created successfully.
*** WinPE x64 ISO: c:\sgshare\sgdeploy\WinPE_ScenarioOutput\Local_Win2008_R2_x6
4_EE\WinPE_x64.iso
18:27:07 - Launching the registered software associated with ISO files...
*** Using ISO File: c:\sgshare\sgdeploy\WinPE_ScenarioOutput\Local_Win2008_R2_x
64_EE\WinPE_x64.iso
18:27:08 - The WinPE x64 build process finished successfully.
SGTKWinPE complete.

IBM System x3850 X5 Specifications

General

Processor Cores	Up to 10 cores per processor
Chipset	Intel 7500
Hard Drive Interface	SAS/SATA
Processor	Intel Xeon E7-4800 series, Intel Xeon E7-8800 series
Memory Slots	64 DIMM slots
Storage	Up to 16 x 2.5" hot-swap SAS/SATA HDDs or SSDs
RAID Support	RAID 0, 1, 5, 6, 10
Network Interface	Integrated Gigabit Ethernet
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware vSphere
Form Factor	4U Rack
