IBM System x3850 X5 Implementation Guide

534 IBM eX5 Implementation Guide
Connecting to the x3690 X5 or x3850 X5
You can use Telnet or SSH to connect to the x3690 X5 or x3850 X5 servers. Follow these
steps:
1. Start a Telnet/SSH session to the IMM IP address.
2. Log in to the IMM. The default user id is USERID and the default password is PASSW0RD,
where the 0 is a zero.
3. The IMM CLI main page appears (Figure 9-92).
Figure 9-92 IMM CLI main page
4. Start SoL with the console 1 command.
The SoL console starts and you see whatever is transmitted over the SoL connection (for
example, the UEFI setup windows). See “Sample output” for examples of what you see over
an SoL connection when the system boots.
Connecting to the HX5
You can use Telnet or SSH for the connection to the BladeCenter HX5. Follow these steps:
1. Start a Telnet/SSH session to the AMM IP address.
2. Log in to the AMM. The default user id is USERID and default password is PASSW0RD, where
the 0 is a zero.
3. The AMM CLI main page appears (Figure 9-93).
Figure 9-93 AMM CLI main page
4. Start SoL with the console -T system:blade[5] command.
The SoL console starts and you see whatever is transmitted over the SoL connection (for
example, the UEFI setup windows). See “Sample output” for examples of what you see over
an SoL connection when the system boots.
Legacy CLI Application
system>
Hostname: MM00145EDF234C
Static IP address: 10.0.0.125
Burned-in MAC address: 00:14:5E:DF:23:4C
DHCP: Disabled - Use static IP configuration.
Last login: Saturday January 1 2000 1:40 from 10.0.0.100 (Web)
system>
Determining the slot number: In this example, we started a SoL session with the
blade in slot 5. To determine the slot number of your blade, select Blade Tasks 
Power/Restart.
