58 IBM eX5 Implementation Guide
Figure 3-2 x3850 X5 internals
Figure 3-3 shows the connectors at the back of the server.
Figure 3-3 Rear of the x3850 X5
Two 1975W rear-access
hot-swap, redundant
power supplies
Four Intel Xeon CPUs
Eight memory cards for
64 DIMMs total –
eight 1066MHz DDR3
DIMMs per card
Six available
PCIe 2.0 slots
Two 60mm hot-swap fans
Eight SAS 2.5” drives or
two eXFlash SSD units
Two 120mm
hot-swap fans
Two front
USB ports
Light path
diagnostics
DVD drive
Dual-port 10Gb
Ethernet Adapter
(PCIe slot 7)
Additional slot for internal
RAID controller
QPI ports 1 & 2
(behind cover)
QPI ports 3 & 4
(behind cover)
Gigabit
Ethernet ports
Serial port
Video port
Four USB
ports
Systems
management
port
10 Gigabit Ethernet ports
(standard on most models)
Power supplies (redundant at
220V power)
Six available PCIe slots
