41
Figure 5-9
Parameter Function
SATA 1-4 here means there are 4 HDDS.
For A series product there are max 2 HDDs. For L series product there are
max 4 HDDs. For S series product there are max 8 HDDs.
When HDD is working properly, system is shown as O. . “_” means there is
no HDD.
SN You can view the HDD amount the device connected to.
2﹡ means the second HDD is current working HDD.
Type The corresponding HDD property.
Total space The HDD total capacity.
Free space The HDD free capacity.
Status HDD can work properly or not.
Page up Click it to view previous page.
Page down Click it to view the next page.
View
recording time
Click it to view HDD record information (file start time and end time).
5.5.2 BPS
Here is for you to view current video data stream (KB/s) and occupied hard disk storage (MB/h).
See
264HFigure 5-10.
