82
Parameter Function
Stop Bit
There are three options: 1/2.
Baud Bit You can select corresponding baud bit here.
Parity
There are five options: none/odd /even/mark/space.
7.3.2.4 Network
Network interface is shown as in 324HFigure 7-25.
Figure 7-25 Network
Please refer to the following sheet for detailed information.
Parameter Function
Ethernet Please select the network card first.
DHCP Dynamically get IP address. You can get the device IP from
the DHCP server if you enabled this function.
TCP Port Default value is 37777.
HTTP Port Default value is 80.
UDP Port Default value is 37778.
Max Connection Network user max amount. The value ranges from 1 to 10.
Network
transmission QoS
You can set the priority between fluency and video quality.
System can automatically adjust the bit stream according to
the network bandwidth.
