11-14
11
SET MODE
Sets the CI-V data transfer rate. 300, 1200, 4800,
9600, 19200 bps and “Auto” are available. (default:
Auto)
When “Auto” is selected, the baud rate is automati-
cally set according to the data rate of connected con-
troller.
CI-V Baud Rate Auto
■ Others set mode (continued)
Transceive operation is possible with the IC-R9500
connected to other Icom transceivers or receivers.
When “ON” is selected, changing the frequency, op-
erating mode, etc. on the IC-R9500 automatically
changes those of connected transceivers (or re-
ceivers) and vice versa.
CI-V Transceive ON
Select [RS-232C] connector output data format from
CI-V and Decode.
• CI-V : Outputs data in CI-V format. (default)
• Decode : Outputs decoded contents in ASCII code
format.
RS-232C Function CI-V
Selects data transmission speed (Baud rate) when
“Decode” is selected in “RS-232C Function” above;
settings are 300, 1200, 4800, 9600 and 19200 bps.
(default: 9600)
Decode Baud Rate 9600
To distinguish equipment, each CI-V transceiver or re-
ceiver has its own Icom standard address in hexa-
decimal code. The IC-R9500’s address is 72h.
When 2 or more IC-R9500’s are connected to an op-
tional CT-17
CI-V LEVEL CONVERTER, rotate the main dial
to select a different address for each IC-R9500; the
range is 01h to 7Fh.
CI-V Address 72h
Selects the connected keyboard type from Japanese,
English, United Kingdom, French, French (Canadian),
German, Portuguese, Portuguese (Brazilian), Span-
ish, Spanish (Latin American) and Italian.
(default: English)
Keyboard Type English
