Icom IC-R9500 - D NAC Squelch Code Setting; D Selective Squelch Code Settings; D Color Setting

13-11
13
CONTROL COMMAND
DD
NAC squelch code setting
The following data sequence is used when sending or
reading the NAC code setting.
DD
Selective squelch code settings
• TGID setting
The following data sequence is used when sending or
reading the TGID code setting.
• UNIT ID setting
The following data sequence is used when sending or
reading the UNIT ID code setting.
DD
Color setting
The following data sequence is used when sending or
reading the color setting.
1000 100 10 1
q
0XXX0XXX0XXX
werty
1000 100 10 1 1000 100 10 1
R (Red) G (Green) B (Blue)
Using 0000–0255 for each color element.
2nd digit: 0–F 3rd digit: 0–F Fixed digit: 0 Fixed digit: 0
q
0
Selectable UNIT ID: 0 0 0 0 0 1 – 9 8 9 6 7 F
0X X X
werty
Fixed digit: 0
0
1st digit: 0–F 4th digit: 0–F
X
Fixed digit: 0
0X0X0
5th digit: 0–F Fixed digit: 0 6th digit: 0–F Fixed digit: 0
2nd digit: 0–F 3rd digit: 0–F Fixed digit: 0 Fixed digit: 0
q
00X X X
wer
Fixed digit: 0
Selectable TGID: 0 0 0 0 – F F F F
0
1st digit: 0–F 4th digit: 0–F
X
Fixed digit: 0
0
2nd digit: 0–F 3rd digit: 0–F Fixed digit: 0 Fixed digit: 0
q
00X X X
we
Fixed digit: 0
0
1st digit: 0–F
Selectable NAC: 0 0 0 – F F F
