11-25
11
SET MODE
Trims the frame of the video signal from [VIDEO IN]
jack. (default: ON)
OFF : Displays the entire area of video signal.
ON : Cuts the frame area (each 4% width of upper,
bottom, left and right areas) and expands the
rest of area.
Selects the wide screen capability ON and OFF.
NOTE: This setting is effective for the full screen
only.
VIDEO IN Trimmin
g
ON
VIDEO IN Wide (Full) ON
■ Display set (Video) mode (continued)
Selects the output video signal from pin 2 of [DATA
IN] socket. (default: VIDEO IN)
VIDEO IN : Outputs a video signal that is the same as
the input from [VIDEO IN] jack.
LCD : Outputs a video signal that is the same as
the LCD.
Adjusts the horizontal width of the output video signal
from pin 2 of [DATA IN] socket. Adjustable range is 1
(narrow) to 4 (wide) in 1 steps. (default: 1)
VIDEO (DATA IN) Output VIDEO IN
VIDEO Out Horizontal Size 1
Selects the setup level of the output video signal from
pin 2 [DATA IN] socket. Selectable items are 0IRE
(JPN NTSC) or 7.5IRE (USA NTSC).
NOTE: Default setting is different depending on
versions.
Adjusts the saturation (vibrancy of the color) of the
output video signal from pin 2 of [DATA IN] jack. Ad-
justable range is 0 (shade of gray) to 100% (vivid
color) in 1% steps. (default: 80%)
VIDEO Out Setup Level 7.5IRE
VIDEO Out Saturation 80
%
Adjusts the hue (color type) of the output video signal
from pin 2 of [DATA IN] jack. Adjustable range is 0
(red) to 100 (green) in 1 steps. (default: 50)
VIDEO Out Hue 50
%
