FC6A S
ERIES
MICROS
MART
L
ADDER
P
ROGRAMMING
M
ANUAL
FC9Y-B1726 11-1
11: WEEK PROGRAMMER INSTRUCTIONS
This chapter describes the week programmer instructions that are used to turn outputs on and off on the specified days of the
week or dates and times.
WKTIM (Week Timer)
Compares the specified day of the week, start time, and end time with the current time and outputs that result.
Note: The WKTIM instruction is compatible with the FC5A Series MICROSmart WKTIM instruction. For details on the WKTIM instruction, see
Chapter 9 "WKTIM (Week Timer)" in the "FC5A Series MICROSmart Pentra User's Manual Advanced Volume".
WKTBL (Week Table)
Sets the specified month and day as a special date.
Note: The WKTBL instruction is compatible with the FC5A Series MICROSmart WKTBL instruction. For details on the WKTBL instruction, see
Chapter 9 "WKTBL (Week Table)" in the "FC5A Series MICROSmart Pentra User's Manual Advanced Volume".
WEEK (Weekly Timer)
Compares the specified day of the week, ON time, and OFF time with the current time and outputs that result.
Note: For details on the WEEK instruction, see "WEEK (Weekly Timer)" on page 11-3.
YEAR (Yearly Timer)
Compares the specified date with the current date and outputs that result. This allows the special dates within a one-year period
to be specified.
Note: For details on the YEAR instruction, see "YEAR (Yearly Timer)" on page 11-16.
D1
＊＊＊＊＊
S2
＊＊＊＊＊
WKTIM S1
＊＊＊＊＊
S3
＊＊＊＊＊
Sn
＊＊＊＊＊
S1
＊＊＊＊＊
WKTBL ・・・
・・・
D1
*****
S2
*****
WEEK S1
*****
S3
*****
D1
＊＊＊＊＊
S2
＊＊＊＊＊
YEAR S1
＊＊＊＊＊
S3
＊＊＊＊＊
