Differences in the week programmer instructions
There are four types of week programmer instructions: the WKTIM instruction, the WKTBL instruction, the WEEK instruction,
and the YEAR instruction. The initial values of the WEEK and YEAR instructions, such as the day of the week, ON time, OFF
time, and special dates, can be easily configured in the dialog box for the instruction. The initial values of the WKTIM and
WKTBL instructions must be configured using data registers.
Comparing the WKTIM and WEEK instructions
Comparing the WKTBL and YEAR instructions
Item WKTIM Instruction WEEK Instruction
Number of instructions that can be
used in one ladder program
No limit 10
Number of patterns that can be
configured in one instruction
1 pattern 20 patterns
Pulse output function No Yes
Initial value configuration method Configure initial values using data registers
Configure initial values using the dialog box
in WindLDR
Configuration pattern preview function No Yes
Item WKTBL Instruction YEAR Instruction
Number of instructions that can be
used in one ladder program
No limit 10
Number of patterns that can be
configured in one instruction
20 patterns 20 patterns
Pulse output function No Yes
Calendar specification methods Specify date
Specify date
Specify day of the week
Specify end of the month
Initial value configuration method
Configure initial values using
data registers in the ladder program
Configure initial values using the dialog box
in WindLDR
Configuration pattern preview function No Yes
