11: W

EEK

ROGRAMMER

NSTRUCTIONS

11-20 FC6A S

ERIES

MICROS

MART

ADDER

ROGRAMMING

ANUAL

FC9Y-B1726

•Preview

The preview shows the ON/OFF state for the output based on the settings configured on the parameter tabs in a calendar.

The dates that are set to ON are highlighted in orange. Three months are shown at one time.

Setting Description

Year Specifies the year to show in the preview.

Scrollbar You can change the month shown in the preview by moving the scrollbar.
