FC6A S ERIES MICROS MART L ADDER P ROGRAMMING M ANUAL FC9Y-B1726 12-17
12: D ISPLAY I NSTRUCTIONS
Modifying Device Values on the HMI Module
The values of the word devices displayed on the HMI module LCD can be modified using the HMI module operation buttons.
The values cannot be modified when the user program is stopped.
[To modify the value of word device CP0]
When the user program is running and the input to the MSG instruction is turned on, the following screen will be displayed on the
LCD.
While the above message is displayed, press and hold the (OK) button and the cursor is displayed on the devices that can be
modified.
Move the cursor to the device you wish to edit using the (up) (down) (left) (right) buttons and press the (OK)
button to change the device in the editable state.
Press the (right) button to move the cursor to the fourth digit, and then use the (up) button to modify the target value to
"65000".
Press the (OK) button to confirm the modifications.
Line A monitor
Plan: CPO Actual:CCO
Diff: DO
Bar Graph CC0
Line A monitor
Plan: 60000 Actual:20000
Diff: 40000
Line A monitorLine A monitor
Diff: 40000
Plan: 60000 Actual:20000
Line A monitor
Diff: 40000
Plan: 60000 Actual:20000
6
Line A monitor
Diff: 40000
Plan: 65000 Actual:20000
5
Line A monitorLine A monitor
Diff: 40000
Plan: 65000 Actual:20000
