FC6A S
ERIES
MICROS
MART
L
ADDER
P
ROGRAMMING
M
ANUAL
FC9Y-B1726 18-81
18: P
ULSE
O
UTPUT
I
NSTRUCTIONS
9. Scale Setting (Velocity)
Select the scale of speed (Y-axis) on the waveform graph from Auto Scaling or Specify Scaling.
10. Specify Time Range
Specifies the range of the graph to display as relative times from the start of monitoring.
The graph is enlarged or shrunk according to this setting.
11. Graph Setting
Select the check boxes for the output ports to display on the waveform graph, and select the color for the graph.
12. Waveform Graph
The waveform graph is drawn in this area. A scrollbar is displayed, and the data for a fixed interval is displayed. Move the
scrollbar and you can view data in the past.
13. ScreenShot
This button saves the waveform graph as an image.
When you click ScreenShot, the Select File dialog box will be displayed, and you can save the graph as a bitmap file.
14. Current Value
This area displays the current values of the waveform graph.
Auto Scaling: The maximum value of the graph is automatically updated according to the maximum value of the data.
Specify Scaling: Manually enter the maximum value of speed (Y-axis). The graph will not be displayed if the value is
larger than the maximum value.
Pulse Output: Displays Pulse output ON or Pulse output OFF.
Pulse Output State: Displays Steady pulse output or Frequency change.
Velocity: Displays the pulse speed being output.
