■ Assigned addresses
Device Unit Range Description
Input Bit
I0 Zero return button
I1 Start movement button
I2 Stop movement button
Internal relay
Bit
M10-M13
RAMP instruction operation status
M50-M53
M100-M103
M150-M153
M1000 Zero return bit
M1001 Start movement bit
M1002 Stop movement bit
Special internal relay M8120 Initialize pulse
Data register
Bit
Word
D10-D20
RAMP instruction control registers
D50-D60
D100-D110
D150-D160
Timer
T0
Timer settings
T1
Counter C0 Counter settings
