IDEC MICROSmart FC6A Series Ladder Programming Manual

FC6A S ERIES MICROS MART L ADDER P ROGRAMMING M ANUAL FC9Y-B1726 24-3
24: C LOCK I NSTRUCTIONS
Examples: TADD
The following examples demonstrate the TADD instruction that will add time data in two different modes.
•Mode 0
•Mode 1
I0
D1
D20
S1
D0
S2
D10
TADD
0
Source 1
9
D0
(Hour)
30
D1
(Minute)
40
D2
(Second)
Source 2
5
D10
(Hour)
10
D11
(Minute)
5
D12
(Second)
+
Destination 1
14
D20
(Hour)
40
D21
(Minute)
45
D22
(Second)
When the result exceeds 23:59:59, the resultant hour data is subtracted by 24, turning on special internal relay M8003 (carry).
Source 1
15
D0
(Hour)
50
D1
(Minute)
40
D2
(Second)
Source 2
10
D10
(Hour)
20
D11
(Minute)
30
D12
(Second)
+
Destination 1
2
D20
(Hour)
11
D21
(Minute)
10
D22
(Second)
SOTU
I0
D1
D200
S1
D8008
S2
D100
TADD
1
Source 2
10
D100
(Hour)
15
D101
(Minute)
25
D102
(Second)
Source 1
7
D8008
(Year)
8
D8009
(Month)
23
D8010
(Day)
+
Destination 1
10
D8012
(Hour)
20
D8013
(Minute)
30
D8014
(Second)
D8011 (Note)
7
D200
(Year)
8
D201
(Month)
23
D202
(Day)
20
D204
(Hour)
35
D205
(Minute)
55
D206
(Second)
4
D203
(D of W)
Note: D8011 in source 1 is not used for execution and does not need to be designated. The day of week is calculated automatically from the
resultant year, month, and day, and stored to D203 of destination 1.
