Source 2
13
D100
(Hour)
39
D101
(Minute)
30
D102
(Second)
When the result exceeds 23:59:59, the resultant hour data is subtracted by a multiple of 24 and the day data is incremented.
Source 1
7
D8008
(Year)
8
D8009
(Month)
23
D8010
(Day)
+
Destination 1
10
D8012
(Hour)
20
D8013
(Minute)
30
D8014
(Second)
4
D8011
(D of W)
7
D200
(Year)
8
D201
(Month)
25
D202
(Day)
0
D204
(Hour)
0
D205
(Minute)
1
D206
(Second)
5
D203
(D of W)
(Note)
Note: D8011 in source 1 is not used for execution and does not need to be designated. The day of week is calculated automatically from the
resultant year, month, and day, and stored to D203 of destination 1.
