IDEC MICROSmart FC6A Series Ladder Programming Manual

FC6A S ERIES MICROS MART L ADDER P ROGRAMMING M ANUAL FC9Y-B1726 A-9
A PPENDIX
Advanced Instruction
Used Data Size (Bytes)
All-in-One CPU Module/
CAN J1939 All-in-One CPU Module
Plus CPU Module
NOP 8 8
MOV (W, I) 16-20 16-28
MOVN (W, I) 16-20 16-28
MOV (D, L) 16-20 16-28
MOVN (D, L) 16-20 16-28
MOV (F) 16-20 16-28
IMOV, IMOVN (W) 20-28 20-44
IMOV, IMOVN (D) 20-28 20-44
IMOV (F) 20-28 20-44
MOVC 16-1044 16-1044
BMOV 16-20 16-32
IBMV, IBMVN 20-28 20-44
NSET (W, I) 16-1544 16-2060
NSET (D, L) 16-1544 16-2060
NSET (F) 16-1544 16-2060
NRS (W, I) 16-24 16-32
NRS (D, L) 16-24 16-32
NRS (F) 16-24 16-32
XCHG (W) 12-16 12-24
XCHG (D) 12-16 12-24
TCCST (W) 16-20 12-24
TCCST (D) 16-20 12-24
CMP (=, <>, <, >, <=, >=) (W, I) 20-28 16-32
CMP (=, <>, <, >, <=, >=) (D, L) 20-28 16-32
CMP (=, <>, <, >, <=, >=) (F) 20-28 16-32
ICMP (>=) 16-28 16-36
ICMP (D, L, F) 16-28 16-36
LC (=, <>, <, >, <=, >=) (W, I) 12-20 12-24
LC (=, <>, <, >, <=, >=) (D, L) 12-20 12-24
LC (=, <>, <, >, <=, >=) (F) 12-20 12-24
ADD (W, I) 16-28 16-36
ADD (D, L) 16-28 16-36
ADD (F) 16-28 16-36
SUB (W, I) 16-28 16-36
SUB (D, L) 16-28 16-36
SUB (F) 16-28 16-36
MUL (W, I) 16-28 16-36
MUL (D, L) 16-28 16-36
MUL (F) 16-28 16-36
DIV (W, I) 16-28 16-36
DIV (D, L) 16-28 16-36
DIV (F) 16-28 16-36
INC (W, I) 12 12-16
INC (D, L) 12 12-16
DEC (W, I) 12 12-16
DEC (D, L) 12 12-16
ROOT (W) 12-20 12-24
ROOT (D) 12-20 12-24
ROOT (F) 12-20 12-24
SUM (W, I) 16-24 16-36
SUM (D, L) 16-24 16-36
SUM (F) 16-24 16-36
RNDM 16-20 16-32
ANDW, ORW, XORW (W) 16-28 16-28
