IDEC MICROSmart FC6A Series Ladder Programming Manual

A PPENDIX
A-10 FC6A S ERIES MICROS MART L ADDER P ROGRAMMING M ANUAL FC9Y-B1726
ANDW, ORW, XORW (D) 16-28 16-28
SFTL, SFTR 16-24 16-40
BCDLS 12-16 12-24
WSFT 16-20 16-32
ROTL, ROTR (W) 12-16 12-20
HTOB (W) 12-20 12-24
BTOH (W) 12-20 12-24
HTOA (W) 16-24 16-32
ATOH (W) 16-24 16-32
BTOA (W) 16-24 16-32
ATOB (W) 16-24 16-32
ENCO (W) 16-20 16-28
DECO 16-20 16-28
BCNT 16-20 16-32
ALT 12 12
CVDT 16-20 16-28
DTDV 12-16 12-24
DTCB 12-16 12-24
SWAP (W) 16-20 16-28
SWAP (D) 16-20 16-28
WKTIM 20-24 20-40
WKTBL 12-92 12-172
WEEK 20-140 24-148
YEAR 28-220 28-228
MSG 20- 20-
DISP 16 16-24
DGRD 16-20 16-28
LABEL 12 12
LJMP 12 12-16
LCAL 12 12-16
LRET 8 8
DJNZ 12-16 12-24
IOREF 12 12
HSCRF 8 8
FRQRF 8 8
COMRF 8 8
DI 12 12
EI 12 12
XYFS 24-272 24 - 528
CVXTY 16-20 16 - 28
CVYTX 16-20 16 - 28
AVRG (W, I) 20-24 20-40
AVRG (D, L) 20-24 20-40
AVRG (F) 20-24 20-40
PULS 12-28 12-36
PWM 12-28 12-36
RAMP 12-36 12-44
RAMPL 36-48 36-48
ZRN 16, 52 16-68
ARAMP 40-316 40-332
ABS 12-16 12-20
JOG 36 36-48
PID 20-28 20-44
PIDA 112-116 112-124
Advanced Instruction
Used Data Size (Bytes)
All-in-One CPU Module/
CAN J1939 All-in-One CPU Module
Plus CPU Module
