IDEC MICROSmart FC6A Series Ladder Programming Manual

FC6A S ERIES MICROS MART L ADDER P ROGRAMMING M ANUAL FC9Y-B1726 A-11
A PPENDIX
PIDD 272-276 272-288
DTML, DTIM, DTMH 16-24 16-36
DTMS 16-24 16-36
TTIM 12 12-16
RAD 12-20 12-24
DEG 12-20 12-24
SIN 12-20 12-24
COS 12-20 12-24
TAN 12-20 12-24
ASIN 12-20 12-24
ACOS 12-20 12-24
ATAN 12-20 12-24
LOGE 20 12-24
LOG10 20 12-24
EXP 20 12-24
POW 16-24 16-32
FIFOF 24 24-32
FIEX 12-16 12-20
FOEX 12-16 12-20
NDSRC (W, I) 16-28 16-40
NDSRC (D, L) 16-28 16-40
NDSRC (F) 16-28 16-40
TADD 16-24 16-36
TSUB 16-24 16-36
HOUR 20-24 20-40
HTOS 12-16 12-24
STOH 12-20 12-24
DLOG 28-408 28-668
TRACE 28-408 28-668
SCRPT 16-20 16-28
SCALE 36-44 36-60
FLWA 24-32 24-48
FLWP 28-36 28-52
UMACRO 24-624 12-812
TXD 20- 20-
RXD 20- 20-
ETXD 20- 20-
ERXD 20- 20-
PING 16-20 16-28
EMAIL 16-20 16-28
Advanced Instruction
Used Data Size (Bytes)
All-in-One CPU Module/
CAN J1939 All-in-One CPU Module
Plus CPU Module
