(3) Stand the stack of cards

vertically after separating

Figure 27 Loading the cards 1

(4) Load the cards on the input

hopper properly and close the

hopper cover.

Figure 28 Loading the cards 2

(5) When insert each one card,

insert the card to the end as left


(Caution! If the printer has a lock device,

a card can’t be inserted one by one.)

Figure 29 Loading the cards 3

Figure 30 Loading the cards 4
