62
4.3. Card Printer Test
Basically Card Printer use standard printer device so you can be used same as general
paper printer. In the case of magnetic stripe, contact, contactless encoder option, you will
need to install appropriate driver and operate individually. Encoding operation will be
controlled by “CARD PRINTER SDK”. You can test all feature of printer by Card printer
Test.
(1) CardPrinterTest
When CardPrinterTest is run, all function can be tested individually.
Figure 89 CardPrinterTest
① Select Printer: select printer to test. In the picture, “IDP SOLID-510 Card Printer”
is the Printer name, SOLID is the Printer ID, and USB001 is the connected port.
② Control : To execute each step to test
③ Print: Print test with CSD file which is designed by Smart ID program.
To Next Page
