idp SOLID-510S - Printer Specifications

94
7. Specification
Model
SOLID-510S
SOLID-510D
SOLID-510L
Printing
Print Type
Dye-Sublimation
Print Area
Edge to Edge
Resolution
300dpi (Color & Mono) / 300x600dpi, 300x1200dpi (Mono only)
Dual Side Printing
Option (with Flipper)
Yes
Yes
Card
Card Feeding
Automatic
Card Size
ISO CR80 or ISO CR79 (option-Factory installed)
Card Thickness
0.38mm (15mil), 1.0mm (40mil)
Card Type
PVC, PET, Composite PVC
Printing Speed
Monochrome
5 sec./card (720 cards/hour)
YMCKO
Max. 17 sec./card (212 cards/hour)
YMCKOK
_
Max. 22 sec./card (164 cards/hour)
Laminating
Mode
_
_
Single & Dual
Film
_
_
0.6mil, 1.0mil
Speed
Simultaneous
_
_
22 sec./card (YMCK)
(Single)
_
_
32 sec./card (YMCKK)
One by One
_
_
43 sec./card (YMCK)
(Single)
_
_
53 sec./card (YMCKK)
Capacity
Input Hopper
100 Cards / 200 Cards with cover open
Output Hopper
Front : 40 Cards / Rear : 100 Cards (Optional Rear-side Stacker)
System
Memory
64MB RAM
Display
2 Line LCD
Control Panel
2 LED Buttons
Supported Platforms
MS Windows 7/ 8/ 10, Mac OS, Linux
Communication
USB, Ethernet (Option)
Power Supply
Free Voltage (AC 100/220V, 50~60Hz)
Power Consumption
48
48
96
Temp. / Humidity
15~35℃ / 35~70%
Dimensions
Millimeter (WxLxH)
165 x 390 x 210
165 x 498 x 210
165 x 675 x 210
Inch (WxLxH)
6.5 x 15.4 x 8.3
6.5 x 19.6 x 8.3
6.5 x 26.6 x 8.3
Weight
Kg / Lbs
4.5 / 10
5.2 / 11.5
8.8 / 19.4
Encoding Options
Magnetic
ISO 7811 (Track I, II, III Read/ Write, HiCo/ LoCo), JIS II
Contact
ISO 7816 (ID-1)
Contactless
MIFARE, ISO 14443 (Type A/ B), ISO 15693, DESFIRE, iCLASS
Certifications
CB, CE, FCC, KC, CCC
Specifications and availability may change without notice.
