IGS BAOHUI HYPER CROSS - Page 25

22
Machine Installation
tag:pic16(21)
OL board
connector A-1P
tag:pic12(11)/
light control board
connector 1P
tag:pic16(6)/
OLboard connector
B-1P
tag:pic11(1)/
IO board power
tag:pic8(1)/
blue 10V-
yellow70V
tag:pic27(11)
vibrator connector
1P
tag:pic14(1)
coin box connector
5559-16P
5559-12P
red
5559-10P
5559-8P
blue
VL-4P-R YL-9P-R
YL-15P-R
5557-16P
5557-12P
red
5557-10P
5557-8P
blue
VL-4P-P
red
YL-9P-P
red
YL-15P-P
red
tag:pic16(1)/
OL board connector
A
tag:pic12(2)/
light control board
connector
tag:16(1)/
OL board
connector B
tag:pic11(2)/
LP-OL-power
tag:pic8(2)/
blue 10V-
yellow70V
tag:pic27(2)
vibrator connector
tag:pic30(1)
coin box connector
tag:pic16(22)/
OL board connector
A-2P
tag:pic12(12)/
light control board
connector 2P
tag:16(6)/
OL board
connector B-2P
tag:pic11(1)/
IO board power
tag:pic8(1)/
blue 10V-
yellow70V
tag:pic27(12)
vibrator connector
2P
tag:pic14(1)
coin box connector
5559-16P
5559-12P
red
5559-10P
5559-8P
blue
VL-4P-R YL-9P-R
YL-15P-R
5557-16P
5557-12P
red
5557-10P
5557-8P
blue
VL-4P-P
blue
YL-9P-P
blue
YL-15P-P
blue
tag:pic16(1)/
OL board connector
A
tag:pic12(2)/
light control board
connector
tag:pic16(1)/
OL board
connector B
tag:pic11(2)/
LP-OL-power
tag:pic8(2)/
blue 10V-
yellow70V
tag:pic27(2)
vibrator connector
tag:pic30(1)
coin box connector
screen 1P
vehicle
body 1P
screen 2P
vehicle
body 2P
coin box part
screen 1P
5557-10P
tag:pic14(1)/
coin box connector
5559-10P
tag:pic14(2)/
coin box connector1P
5559-10P
tag:pic14(3)/
coin box connector2P
5557-10P
tag:pic14(1)/
coin box connector
YL-6P-P
tag:pic13(1)/volume
board connector
YL-6P-R
tag:pic13(3)/volume
board connector
YL-6P-R
tag:pic13(3)/volume
board connector
YL-6P-P
tag:pic13(2)/volume
board connector
blue 5557-4P
tag:pic15(1)/light
box connector1P
blue 5559-4P
tag:pic42(1)/light
power connector1P
blue 5559-4P
tag:pic42(2)/light
power connector2P
blue 5557-4P
tag:pic15(2)/light
box connector2P
5557-6P
tag:pic14(1)/
coin box control
5559-6P
tag:pic43(1)/1P
power control
5559-6P
tag:pic43(2)/2P
power control
5557-6P
tag:pic14(1)/
coin box control
screen 2P
Disassembly and Reassembly Diagram for Transport
