126
HDK-99 1803 VER1 (E)
7.1 HDK-99 Specifications
■
Output signals (FA-97A)
Item Rating Remarks
1 Main line video signal
Y,Pb,Pr 4:2:2 digital serial (optical connector)
Y,Pb,Pr 4:2:2 digital serial (75Ω BNC)
BTA S-004B compliant
2 Monitor video signal
RET image HD SDI 4:1:1 or VF HD SDI 4:2:2 Select with MENU
3 Analog signal
G, B, R (D-Sub SE)
HD Y or NTSC/PAL VBS output (MON output terminal)
NTSC/PAL VBS output (AUX OUT terminal)
Interface with SE-H700 or SE-H750
Possible to select Q-TV output with MENU.
4 Q-TV
Analog video signal 2 channels (75Ω BNC connector) BS/CCU required that can handle 2 channel input.
5 Intercom signal
0 dBs 2 channels (XLR type) PROD, ENG
■
Input signals (FA-97A)
Item Rating Remarks
1
Return video signal
Y, Pb, Pr, 4:1:1/Q-TV Optical connector
2
External SYNC signal
SYNC 0.6Vp-p±6dB
3
Audio signal
-60 to +4dB (Variable) / -20dB (Fixed) 600
Ω
Balanced two channels
4
Intercom signal
2 channels (XLR type or 110 type) ENG, PROD
■
Camera cables
Item Rating Remarks
1 Standard cable
2SM - 9.2 - 37.5
2 Studio-use cable
2SM - 16 - 37.5
3 Cable configuration
Two single-mode type quartz ber optic cables
4 power cables
2 control cables
HEAD-->CCU, CCU-->HEAD (one cable for each)
4 Power cables
37.5Ω/Km per cable
5 Control cables
113Ω/Km per cable
■
Applicable standards
Safety Standards : CE / FCC
To Next Page
