7.1 HDK-99 Specifications
7
SPECIFICATIONS
7.1 HDK-99 Specifications
■
Ratings
Item Rating Remarks
1 Scanning system
1080i/59.94, 1080P/29.97, 1080P/23.98, 1080P/59.94,
1080i/119.88, 720P/59.94
1080i/50, 1080P/25, 1080P/50,1080i/100, 720P/50
2 Image sensor
2/3 type MOS sensor × 3 Total pixels 2.6M
3
Effective number of
pixels
1920 (H)×1080 (V)
4 Sensitivity
F11 1080i/59.94
5 Optical system
2/3 type R, G, B prism
6 Lens mount
BTA S-1005B
7 Optical filter
1 2 3 4 5
ND CAP CLEAR 1/4 1/16 1/64
A B C D E
CC CROSS 3200K 4300K 6300K 8000K
8 Sampling frequency
74.25 MHz/1.001 or 74.25 MHz
9 VF
2-inch color VFL201A
10
Power source
voltage
DC+11 to +16V
11
Ambient
temperature
Operation temperature : -20
℃
to +45
℃
Storage temperature : -30
℃
to +60
℃
12 Ambient humidity
30
％
to 90
％
No condensation.
13 EMI
FCC Class A
14 External dimensions
Approx. W138.5×H270×D337 Not including projections.
15 Weight
Camera head + Fiber adapter : 4.9 kg
2-inch : 820 g
7.4-inch : 1.6 kg
FA-97A
VFL201A
VFE741A (w/o Attachment plate)
■
Performance
Item Rating Remarks
1 S/N ratio
62dB (typ.) 1080i/59.94 Dened only in 1080i / 59.94.
2
Degree of modulation
60 % (typ.) at f4 Dened only in 1080i / 59.94.
3 Limiting resolution
1000 TVL (typ.) Dened only in 1080i / 59.94.
4 Registration error
0.02 % or less Not including lens distortion.
5 Contour correction
Horizontal boost frequency 13 MHz - 22 MHz
6 GAIN
-6, -3, 0, +3, +6, +9, +12, +18dB
7 GAMMA
OFF, 0.35, 0.4, 0.45, CUSTOM1 - 5
CUSTOM 1 - 5 supports HLG.
CUSTOM 5 is HLG curve by default.
8 Electronic shutter
1/100, 1/120, 1/250, 1/500,1/1000, 1/2000
9 Power consumption
HEAD : 18W
FA : 10W
2-inch VF : 4.1W
7.4-inch VF : 20W
