85
HDK-99 1803 VER1 (E)
5
CAMERA SETTINGS and ADJUSTMENT
5.2 Settings from the Menu
Menu Configuration and content
The following lists the camera menu conguration.
■
MENU (Simple Menu)
The simple menu is the same as MENU (1/4) described below. Refer to items in MENU (1/4) for details of each menu.
■
MENU (1/4)
*1
Menu Item
Initial
setting
Setting value Description, Remarks
MENU DATA
ALL VF
VF DISPLAY
―
DISPLAY MODE
2 OFF, 1, 2
OFF : The markers and characters are constantly OFF, and
only the warning messages are displayed.
1 : Only the markers are constantly displayed.
Information related to characters is displayed for
2 seconds during function operation and when
changing parameters.
2 :
The markers and characters are displayed at all times.
✔ ✔
―
VF DTL
35 0 to 100 It sets the detail amount to be displayed on the VF.
✔ ✔
―
MARKER/CHAR LVL
100 1 to 100
Sets the brightness levels of the markers and characters. The
brightness level gets dark in the direction of "1".
✔ ✔
―
FRAME MARKER
ON-16:9
ON-16:9, ON-14:9, ON-
13:9, ON-4:3, OFF
Sets the frame marker.
✔ ✔
―
VF ASPECT
16:9 16:9, 4:3 Sets the VF aspect ratio.
✔ ✔
―
SIDE MASK
OFF
OFF, ON-4:3,
ON-13:9, ON-14:9
Sets the side mask.
✔ ✔
―
CONTRAST
50 0 to 100 Adjusts the side mask contrast level.
✔ ✔
―
BRIGHT
40 0 to 100 Adjusts the side mask brightness level.
✔ ✔
―
SAFETY AREA
ACTION ACTION, TITLE
ACTION :
Area marker of 93% of the screen height and width.
TITLE :
Area marker of 89% of the screen height and width.
✔ ✔
―
SAFETY MARKER
ON-16:9 ON-4:3, ON-16:9, OFF Sets the safety marker.
✔ ✔
―
CENTER MARKER
TYPE3
TYPE1, TYPE2, TYPE3,
OFF
Sets the center marker.
✔ ✔
―
FOCUS INDICATE
ON-STD
OFF, ON-STD,
ON-METER, ON-FEET
Only active when using the serial lens.
✔ ✔
―
ZOOM INDICATE
ON OFF, ON Only active when using the serial lens.
✔ ✔
―
AUTO VF ASPECT
OFF ON, OFF
Switches the VF aspect ratio in linked motion with the output
mode of the BS/CCU down converter.
✔ ✔
Overlaps the striped pattern signal on the image if the image
level has exceeded the individual DETECT LEVELS. The
zebra indicator goes ON/OFF with the VF special switch.
-Zebra 1 signal : Fine, slanted striped pattern signal flowing
toward the upper right of the screen.
Use to control the tone of the entire screen.
-Zebra 2 signal : Thick, slanted striped pattern signal
flowing to the lower right of the screen.
Used for controlling the tone of the subject,
such as face tone, etc.
ZEBRA INDICATOR
―
ZEBRA1 DETECT
100% 30 to 109% Sets the DETECT LEVEL of the 1st zebra indicator.
✔ ✔
―
ZEBRA2 IND
OFF OFF, ON Selects whether there is a 2nd zebra indicator or not.
✔ ✔
―
ZEBRA2 DETECT
70% 30 to 109% Sets the DETECT LEVEL of the 2nd zebra indicator.
✔ ✔
ZEBRA IND LVL
78 1 to 100 Adjusts the overlap level of the zebra indicator.
✔ ✔
Adjusts the overlap amount of the VF image focusing edge
signal (VF DTL).
VF DTL
―
VF DTL
35 0 to 100
Sets the VF detail amount. The detail amount decreases in
the direction of "0" and increases in the direction of "100".
✔ ✔
―
BOOST FREQ
18MHz
10MHz, 15MHz, 18MHz,
18MHzWIDE
Selects the frequency to be boosted.
✔ ✔
NOISE SUP
5 0 to 100 Sets the noise reduction in the VF DTL signal.
✔ ✔
