5.2 Settings from the Menu
Menu Item
Initial
setting
Setting value Description, Remarks
MENU DATA
ALL VF
FOCUS ASSIST
―
ASSIST AREA
TRIGGER
ON
TRIGGER ON,
ALWAYS ON, OFF
Sets the ASSIST AREA display.
Select TRIGGER ON if you wish to display with the trigger
of lens operation, etc.
✔ ‐
―
TRIGGER
FOCUS
FOCUS, FOCUS/ZOOM,
LENS VTR
Trigger to display ASSIST AREA.
This setting is used when TRIGGER ON is selected.
When "FCS ASSIST TRIG" is set to the VTR button on the
lens, "FOCUS TRIG" will be the dedicated function of the
VTR switch.
✔ ‐
―
AREA ON/OFF SW
NONE NONE, LENS VTR Selects the switch to turn ON/OFF the ASSIST AREA.
✔ ‐
―
VF DOT BY DOT
UNLINK UNLINK, LINK
Sets whether a control signal is sent to a VF having a DOT
BY DOT display function.
✔ ‐
―
FOR RET
ON ON, OFF
Sets whether to display the ASSIST AREA or not when
switching to the RET signal.
✔ ‐
―
ASSIST DATA
NO.1 N0.1 to N0.4
Selects the ASSIST DATA compiled in the ASSIST DATA
SETTING menu.
✔ ‐
ASSIST DATA SETTING
―
SW ACTION
ALTERNATE
ALTERNATE,
MOMENTARY
If the trigger has been assigned to the LENS VTR SW, sets
whether it is momentary operation or alternate operation.
✔ ‐
―
AREA DISP TIME
1.0S
0.0S to 5.0S
(0.5sec increments)
Sets the time from trigger detection until the focus assist area
is erased.
✔ ‐
―
AREA SIZE
15 1 to 100
Sets the focus assist area range.
If set to "100", it is the entire screen domain.
✔ ‐
―
AREA LEVEL
60% 25% to 100% Sets the image level of the ASSIST AREA.
✔ ‐
―
AREA COLOR
MONO MONO, COLOR, NEGA
Sets whether the ASSIST AREA image should be color,
monochrome or negative.
✔ ‐
―
AREA MARKER
OFF OFF, ON Sets whether the assist area frame marker is displayed or not.
✔ ‐
―
EDGE BOOST
LEVEL
55 1 to 100 Sets the boost level of the edge signal.
✔ ‐
―
EDGE COLOR
MONO
MONO, CYAN,
MAGENTA, YELLOW,
GREEN, RED, BLUE
Sets the color of the edge signal.
✔ ‐
STORE DATA
--- N0.1 to N0.4
The contents set in the ASSIST DATA SETTING menu are
stored as ASSIST DATA. Select the numbers you wish to
store from No. 1 to No. 4 and write over the present data to
store them.
‐ ‐
MIC GAIN CONTROL
―
MIC1 STEP
-40dB
+4dB, 0dB, -10dB,
-20dB, -30dB, -40dB,
-50dB, -60dB
The MIC1 gain is changed step by step.
✔ ‐
―
MIC1 FINE
0.0 -100 to 100
Fine adjustment of the MIC1 gain. The gain decreases about
-8 dB with -100, and increases about +8 dB with +100.
‐ ‐
―
MIC2 STEP
-40dB
+4dB, 0dB, -10dB,
-20dB, -30dB, -40dB,
-50dB, -60dB
The MIC2 gain is changed stepwise.
✔ ‐
MIC2 FINE
0.0 -100 to 100
Fine adjustment of the MIC2 gain. The gain decreases about
-8 dB with -100, and increases about +8 dB with +100.
‐ ‐
RETURN SELECT MODE
―
RET-2/MIC SEL
RET-2 RET-2, MIC
Allocates a function to the RET-2/MIC button on top of
handle and on left side of camera.
✔ ‐
―
VTR SW SEL
RET-2 RET-2, MIC, DBD
Sets a function to the VTR SW button on the lens.
If the FOCUS ASSIST menu (TRIGGER or AREA ON/OFF SW)
is set to LENS VTR, it becomes the dedicated function of the VTR
switch.
✔ ‐
RET PRIORITY
NOTHING
NOTHING, RET-1,
RET-2
If a RET-1 or RET-2 image is not displayed in the viewfinder,
sets the output signal to MON SDI (during RETURN
setting).
NOTHING : Sets to RET image last displayed in VF.
RET1 : Sets to RET-1 image.
RET2 : Sets to RET-2 image.
✔ ‐
COLOR VF MODE
―
COLOR VF
ON AUTO, ON
AUTO : It automatically recognizes the color VF and
switches the VF VIDEO signal to the R/G/B
output.
ON : It switches the VF VIDEO signal output to R/G/B.
✔ ✔
―
VF SELECT
(R/G/B)
Y, R, G, B, R+G+B,
(R/G/B)
It sets the VF video output.
R/G/B can be set when the color VF is mounted or when
COLOR VF MODE is ON.
✔ ✔
FRONT TALLY
ENABLE ENABLE, DISABLE It sets VF FRONT TALLY active or always off.
✔ ✔
SW FUNCTION
―
RET-1 (HANDLE)
RET-1
RET-1, ZOOM-,
FOCUS-, NONE
Sets the button control of RET-1 and RET-2/MIC on the top
of the handle.
When assigning to ZOOM, FOCUS, a serial lens is required.
✔ -
―
RET-2 (HANDLE)
RET-2
RET-2, ZOOM+, FOCUS+,
NONE
✔ -
―
ZOOM SPEED
15 1 to 100
Sets the operational speed of ZOOM, FOCUS control. The
speed is slower for "0" and faster for "100".
✔ -
FOCUS SPEED
15 1 to 100
✔ -
