HDK-99 1803 VER1 (E)
5
CAMERA SETTINGS and ADJUSTMENT
5.2 Settings from the Menu
Menu Item
Initial
setting
Setting value Description, Remarks
MENU DATA
ALL VF
INFORMATION
―
MPU MODULE SW
---
MPU_MULTI_B substrate
DIP SW
Displays the DIP switch settings of the MPU_MULTI_B
module.
- -
―
WORKING TIME
---
****.*H (information
display)
Displays the total accumulated operation time of the camera
up to the present.
- -
―
SUB TIME
---
****.*H (information
display), RESET
Displays the camera's calculated operation time.
Differs from WORKING TIME because it can be reset by
the user.
- -
---
STRB****V**.**.**
(information display)
Number to control the structure of the camera software and
FPGA.
(Regarding the SDI-TRX, because it is on the FA side, it is
not included in this control number).
- -VERSION
―
MPU ROM
--- (information display) Displays the camera software version.
- -
―
CHECK SUM
--- (information display) Displays the checksum of the software version.
- -
―
D.PROC
---
(information display) Displays the FPGA version.
- -
―
DRIVE PULSE
---
―
MPU
---
SDI-TRX
---
*1 : When the MENU DATA is read from the SD CARD, it can set whether the entire MENU is read or only items related to VF are read.
It reads the settings of items with a check mark.
