1
OUTLINE
7
HDK-99 1803 VER1 (E)
1.2 Operating Systems
■
Network Connection (Basic bus connection)
Camera Head
Camera Head
Camera Head
CAMERA
MONITOR
CCU-980
CAMERA
MONITOR
CCU-980
CAMERA
MONITOR
SWITCH
*2
MCP-300
OCP-300
OCP-300
OCP-300
PM
WFM
HD-SDI
PM
WFM
HD-SDI
PM
WFM
HD-SDI
Ethernet
Ethernet
Ethernet
LAN cable
LAN cable
LAN cable
LAN cable
LAN cable
LAN cable
LAN cable
Note:
- The OCP connector and CSU
connector on the CCU cannot
be used with the network
connector at the same time in
this conguration.
Term:
PoE (Power over Ethernet)
PoE is the technology to supply
power with LAN cable.
Caution:
*2- When OCP is compatible
with PoE+ (IEEE 802.3at),
the PoE function can be used
in this connection.
To Next Page
