20
HDK-99 1803 VER1 (E)
2.1 Camera and Viewfinder
①
Lens mount
Various 2/3" broadcast HD lenses can be mounted.
②
LENS LOCK lever
Locks the lens mount. Turn the lens mount ring using this lever to secure the lens after the
lens is inserted into the lens mount.
③
MIC button
The intercom microphone is turned ON while this button is pressed.
④
SET button
Conrms the selected item or value on the menu.
⑤
ROTARY PULSE switch
Selects a shutter speed or other settings on the menu.
⑥
VF CHAR button
While this button is pressed, the camera status and various markers appear on the
viewnder. Also, using this button with the ROTARY PULSE switch will make the menu
appear or disappear.
⑦
P.FUNC switch
Turns ON/OFF the functions allocated by the user. The user can allocate the following
functions: IRIS+CORR, IRIS++CORR, AUTO KNEE, SKIN DTL, SOFT DTL, and
SCENE FILE
ON : Turns ON the allocated function.
OFF : Turns OFF the allocated function.
SEL : Set this switch to "SEL" when allocating the function.
⑧
LENS connector
Connects a 12-pin lens cable. It is compatible with BTA spec lenses..
⑨
Cable clamp
Secures the microphone cable and lens cable (pigtail cable).
Reference:
Refer to
"5. CAMERA
SETTINGS and
ADJUSTMENT : Basic
Operation of the Menu"
(P82)
for how to open and
close the menu.
Reference:
Refer to
"5. CAMERA
SETTINGS and
ADJUSTMENT : Allocating
Functions to the P.FUNC
Switch" (P80)
for how to
allocate functions to the P.FUNC
switch.
Reference:
Refer to
"7. SPECIFICATIONS
: Lens Connector" (P131)
for the pin functions of the lens
connector.
