Page 82 Operation Manual
B.5 Touchscreen – Viewer & Job Control
The Viewer Control screen allows the operator to control and modify the image on the
TFT flat screen.
Picture 65: Viewer & Job Control screen
The preview section (1) represents the TFT flat screen.
The scanned image is displayed on the TFT flat screen and with reduced quality in the
preview section right beside the controller elements.
Picture 66: Scanned image in preview area
The ICC profile for the external monitor is integrated into the image
if the checkbox is selected.
