SD1 Series Inverters Function Parameters
-95-
Function
code
Name Description Default Modify
0: Action during the automatic reset period
1: No action during the automatic reset period
P11.16
Extension
function
selection
0x000~0x111
Ones place: Automatic frequency-drop at voltage
drop
0: Disable
1: Enable
Tens place: The second ACC/DEC time
selection
0: Disable
1: Enable
When the operation is above P08.36, ACC/DEC
time is switched to the second ACC/DEC time
Hundreds place: STO function selection
0: STO alarm locked
Alarm locked means when STO appears, reset is
a must after state recovery.
1: STO alarm unlocked
STO alarm unlocked means when STO appears,
STO alarm will disappear
automatically after
state recovery.
Note: STL1~
STL3 are fault lock and cannot be
reset.
0x000
○
P13 Group SM Control
Function
code
Name Description Default Modify
P13.09
Frequency
switching
point
0.00~630.00 50.00 ○
P13.13
Short circuit
brake current
After the inverter starts, when P01.00
=0, set
P13.14 to non-
zero value and begin short circuit
braking.
After the inverter
stops, when the operation
frequency is less than P01.09, set P13.15 to
non-zero value and begin stopping short-circuit
braking and then DC braking.
Setting range of P13.13: 0.0~150.0% (relative to
0.0%
○
P13.14
Hold time of
short circuit
brake at start
0.00s ○
P13.15
Hold time of
short circuit
brake at stop
0.00s ○
