IMO SD1 Series - P10 Group Simple PLC and Preset Speed Control

SD1 Series Inverters Function Parameters
-88-
Function
code
Name Description Default Modify
P09.20
Low point
frequency of
PI
D parameter
switching
0.00Hz~P09.21
When the ramp frequency is no greater than
P09.20
, current PID parameters are
P09.17~P09.19
. When the ramp frequency is no
less than P09.21, current PID
parameters are
P09.04~P09.06
. The medium frequency range is
the linear interpolation values between the two
PID parameter groups.
5.00Hz ○
P09.21
High point
frequency of
PI
D parameter
switching
P09.20~P00.03 10.00Hz ○
P10 Group Simple PLC and Preset Speed Control
Function
code
Name Description Default Modify
P10.00
Simple PLC
mode
0: Stop after running once; the inverter stops
automatically after running for one cycle, and it
can be started only after receiving running
command.
1: Keep running in the final value after running
once. The inverter keeps the running frequency
and direction of the last section after a single
cycle.
2: Cyclic running; the inverter
enters the next
cycle after completing one cycle until receiving
stop command and stops.
0 ○
P10.01
Simple PLC
memory
selection
0: No memory after power-off
1: Memory after power-off; PLC memorizes its
running step and frequency before power-off.
0 ○
P10.02 Preset speed 0
100.0% of the frequency setting corresponds to
the max. frequency P00.03.
When selecting simple PLC running, set
P10.02~P10.33
to define the running frequency
and direction of all stages.
Note: The symbol of Preset
determines the
running direction of simple PLC. The negative
0.0%
○
P10.03
Running time
of step 0
0.0s
○
P10.04 Preset speed 1
0.0%
○
P10.05
Running time
of step 1
0.0s
○
