SD1 Series Inverters Product Overview
-10-
2.5 Product Nameplate
Figure 2-1 Product nameplate
Note: These ar
e product nameplate examples for the standard products. The mark such as
CE/TUV/IP20/UL will be applied according to the actual condition. The 1PH/3PH 220V models
of 2.2kW and lower and the 3PH 380V models of 11kW and lower have been UL certified.
2.6 Mode Code
The mode code contains information on the inverter. Users can find the mode code on the
nameplate attached to the inverter or the simple nameplate.
SD1 – 2.5A – 43
① ②
③
Figure 2-2 Product model
Key No.
Detailed content
Abbreviation of
①
Product
SD1 = Series Name
