IMO SD1 Series - 2.7 Rated Specifications

SD1 Series Inverters Product Overview
-11-
Key No.
Detailed
description
Detailed content
Rated current ②
Rated Output
Current
2.5A = 2.5Amps continuous rating
Voltage class ③
Supply Voltage
21: AC 1PH 200V (-15%) ~240V
(+10%)
23: AC 3PH 200V (-15%) ~240V
(+10%)
43: AC 3PH 380V (-15%) ~440V (+10%)
2.7 Rated Specifications
Model
Voltage
degree
Rated
output
power (kW)
Rated input
current (A)
Rated output
current (A)
STO
function
SD1-2.5A-21
Single
phase 230V
0.4
6.5
2.5
SIL2
SD1-4.2A-21
0.75
9.3
4.2
SD1-7.5A-21
1.5
15.7
7.5
SD1-10A-21
2.2
20
10
SD1-2.5A-23
Three phase
230V
0.4
3.7
2.5
SD1-4.2A-23
0.75
5
4.2
SD1-7.5A-23
1.5
7.7
7.5
SIL3
SD1-10A-23
2.2
11
10
SD1-16A-23
4
17
16
SD1-20A-23
5.5
21
20
SD1-30A-23
7.5
31
30
SD1-2.5A-43
Three phase
400V
0.75
3.4
2.5
SIL2
SD1-4.2A-43
1.5
5.0
4.2
SD1-5.5A-43
2.2
5.8
5.5
SD1-9.5A-43
4
13.5
9.5
SIL3
SD1-14A-43
5.5
19.5
14
SD1-18.5A-43
7.5
25
18.5
SD1-25A-43
11
32
25
SD1-32A-43
15
40
32
SD1-38A-43
18.5
47
38
SD1-45A-43
22
51
45
SD1-60A-43
30
70
60
SD1-75A-43
37
80
75
SD1-92A-43
45
98
92
SD1-115A-43
55
128
115
SD1-150A-43
75
139
150
