IMO SD1 Series - Inverter Chart

SD1 Series Inverters Dimension Drawings
-146-
Installation bracket 1 Customer installation dimensions
Installation bracket 2 Customer installation dimensions
Figure B-3 Outline and installation dimensions
B.2 Inverter Chart
Figure B-4 Wall mounting of 0.75~2.2kW inverters (Dimension unit: mm)
Model W1 W2 H1 H2 D1 D2
Mounting
hole
diameter (d)
Weight
(kg)
