SD1 Series Inverters Dimension Drawings
-147-
Model W1 W2 H1 H2 D1 D2
Mounting
hole
diameter (d)
Weight
(kg)
SD1-2.5A-21
80.0
60.0
160.0
150.0
123.5
120.3
Ø 5
0.9
SD1-4.2A-21
80.0
60.0
160.0
150.0
123.5
120.3
Ø 5
0.9
SD1-7.5A-21
80.0
60.0
185.0
175.0
140.5
137.3
Ø 5
1.2
SD1-10A-21
80.0
60.0
185.0
175.0
140.5
137.3
Ø 5
1.2
SD1-2.5A-23
80.0
60.0
185.0
175.0
140.5
137.3
Ø 5
1
SD1-4.2A-23
80.0
60.0
185.0
175.0
140.5
137.3
Ø 5
1
SD1-2.5A-43
80.0
60.0
185.0
175.0
140.5
137.3
Ø 5
1
SD1-4.2A-43
80.0
60.0
185.0
175.0
140.5
137.3
Ø 5
1
SD1-5.5A-43
80.0
60.0
185.0
175.0
140.5
137.3
Ø 5
1
Figure B-5 Rail mounting of inverters of 1PH 220V/3PH 380V (≤2.2kW) and 3PH 220V
(≤0.75kW) (Dimension unit: mm)
Model W1 H1 H3 H4 D1 D2
Mounting
hole
diameter
(d)
Weight
(kg)
SD1-2.5A-21
80.0
160.0
35.4
36.6
123.5
120.3
Ø 5
0.9
SD1-4.2A-21
80.0
160.0
35.4
36.6
123.5
120.3
Ø 5
0.9
SD1-7.5A-21
80.0
185.0
35.4
36.6
140.5
137.3
Ø 5
1.2
SD1-10A-21
80.0
185.0
35.4
36.6
140.5
137.3
Ø 5
1.2
SD1-2.5A-23
80.0
185.0
35.4
36.6
140.5
137.3
Ø 5
1
SD1-4.2A-23
80.0
185.0
35.4
36.6
140.5
137.3
Ø 5
1
SD1-2.5A-43
80.0
185.0
35.4
36.6
140.5
137.3
Ø 5
1
SD1-4.2A-43
80.0
185.0
35.4
36.6
140.5
137.3
Ø 5
1
SD1-5.5A-43
80.0
185.0
35.4
36.6
140.5
137.3
Ø 5
1
