IMO SD1 Series - P08 Group Enhanced Functions

SD1 Series Inverters Function Parameters
-74-
Function
code
Name Description Default Modify
P07.45
Bus voltage of the last fault
0.0V
●
P07.46
Max. temperature of the last fault
0.0°C
●
P07.47
Input terminals state of the last fault
0
●
P07.48
Output terminals state of the last fault
0
●
P07.49
Reference frequency of the last but one fault
0.00Hz
●
P07.50
Ramp reference frequency of last but one fault
0.00Hz
●
P07.51
Output voltage of the last but one fault
0V
●
P07.52
Output current of the last but one fault
0.0A
●
P07.53
Bus voltage of the last but one fault
0.0V
●
P07.54
Max. temperature of the last but one fault
0.0°C
●
P07.55
Input terminals state of the last but one fault
0
●
P07.56
Output terminals state of the last but one fault
0
●
P08 Group Enhanced Functions
Function
code
Name Description Default Modify
P08.00
ACC time 2
When the terminal acts as ACC/DEC time
selection
(see terminal function settings in the
P05 group)
, you need to select four groups of
ACC/DEC time through state combinations of
these two terminals.
T
erminal
1 (21)
Terminal
2 (22)
ACC/DEC time
setting
Parameters
OFF OFF ACC/DEC time 1
P00.11/
P00.12
ON OFF ACC/DEC time 2
P08.00/
P08.01
OFF ON ACC/DEC time 3
P08.02/
P08.03
ON ON ACC/DEC time 4
P08.04/
P08.05
Refer to P00.11 and P00.12
for detailed
definition.
The first group of ACC/DEC
time is the factory
default one.
Setting range: 0.0~3600.0s
Depend
on
model
○
P08.01
DEC time 2
○
P08.02
ACC time 3
P08.03
DEC time 3
○
P08.04
ACC time 4
○
P08.05 DEC time 4 ○
P08.06
Jog running
frequency
This parameter is used to define the reference
frequency during jogging.
5.00Hz ○
