C.3.2 control cables
All analog control cables and cables used for frequency input must be shielded cables.
Relay cables need to be those with metal braided shield layers.
Note:
Analog signals and digital signals cannot use the same cables, and their cables must be
arranged separately.
Check the insulation conditions of the input power cable of an inverter according to the local
regulations before connecting it.)
Model
Recommended
cable size (mm
2
)
Size of connectable
cable
(mm
2
)
Terminal
screw
Tightening
torque (Nm)
RST
PE
RST
P1, (+) PE
UVW
UVW
SD1-2.5A-21
1.5
1.5
1~4
1~4
1~4
M3
0.8
SD1-4.2A-21
1.5
1.5
1~4
1~4
1~4
M3
0.8
SD1-7.5A-21
2.5
2.5
1~4
1~4
1~4
M3
0.8
SD1-10A-21
2.5
2.5
1~4
1~4
1~4
M3
0.8
SD1-2.5A-23
1.5
1.5
1-1.5
1-1.5
1-1.5
M3
0.8
SD1-4.2A-23
1.5
1.5
1-1.5
1-1.5
1-1.5
M3
0.8
SD1-7.5A-23
2.5
2.5
1.5~6
2.5~6
2.5~6
M4
1.13
SD1-10A-23
2.5
2.5
1.5~6
2.5~6
2.5~6
M4
1.13
SD1-16A-23
2.5
2.5
1.5~6
2.5~6
2.5~6
M4
1.13
SD1-20A-23
4
4
4~10
4~10
4~10
M5
2.3
SD1-30A-23
6
6
4~10
4~10
4~10
M5
2.3
SD1-2.5A-43
1.5
1.5
1~1.5
1~1.5
1~1.5
M3
0.8
SD1-4.2A-43
1.5
1.5
1~1.5
1~1.5
1~1.5
M3
0.8
SD1-5.5A-43
1.5
1.5
1~1.5
1~1.5
1~1.5
M3
0.8
SD1-9.5A-43
2.5
2.5
2.5~6
2.5~6
2.5~6
M4
1.13
SD1-14A-43
2.5
2.5
2.5~6
2.5~6
2.5~6
M4
1.13
SD1-18.5A-43
4
4
4~10
4~10
4~10
M5
2.3
SD1-25A-43
6
6
4~10
4~10
4~10
M5
2.3
SD1-32A-43
6
6
4~10
4~10
4~10
M5
2.3
SD1-38A-43
10
10
10~16
10~16
10~16
M5
2.3
SD1-45A-43
16
16
10~16
10~16
10~16
M5
2.3
SD1-60A-43
25
16
25~50
25~50
16~25
M6
2.5
SD1-75A-43
25
16
25~50
25~50
16~25
M6
2.5
SD1-92A-43
35
16
35~70
35~70
16~35
M8
10
SD1-115A-43
50
25
35~70
35~70
16~35
M8
10
