SD1 Series Inverters Function Parameters
-98-
Function
code
Name Description Default Modify
action selection
0: Yes
1: No
Tens place: Communication encryption
0: Disabled
1: Enabled
Hundreds place: User-
defined communication
command address
0: Disabled
1: Enabled
P14.07
User-defined
address for
running
commands
0x0000~0xffff
0x1000
○
P14.08
User-defined
address for
frequency
setting
0x0000~0xffff
0x2000
○
P17 Group Status Viewing
Function
code
Name Description Default Modify
P17.00
Setting
frequency
Display the set frequency of the inverter
Range: 0.00Hz~P00.03
●
P17.01
Output
frequency
Display the output frequency of the inverter
Range: 0.00Hz~P00.03
●
P17.02
Ramp
reference
frequency
Display the ramp reference frequency of the
inverter
Range: 0.00Hz~P00.03
●
P17.03 Output voltage
Display the output voltage of the inverter
Range: 0~1200V
●
P17.04 Output current
Display the output current of the inverter
Range: 0.0~5000.0A
●
P17.05 Motor speed
Display the rotation speed of the motor.
Range: 0~65535RPM
●
P17.06 Torque current
Display the torque current of the inverter
Range: 0.0~5000.0A
●
P17.07
Magnetized
current
Display the magnetized current of the inverter
Range: 0.0~5000.0A
●
