SD1 Series Inverters Function Parameters
-97-
Name Description Default Modify
6: No check (N, 7, 1) for ASCII
7: Even check (E, 7, 1) for ASCII
8: Odd check (O, 7, 1) for ASCII
9: No check (N, 7, 2) for ASCII
10: Even check (E, 7, 2) for ASCII
11: Odd check (O, 7, 2) for ASCII
12: No check (N, 8, 1) for ASCII
13: Even check (E, 8, 1) for ASCII
14: Odd check (O, 8, 1) for ASCII
15: No check (N, 8, 2) for ASCII
16: Even check (E, 8, 2) for ASCII
17: Odd check (O, 8, 2) for ASCII
P14.03
Communication
response delay
0~200ms
It means the interval time between the drive
receiving
the data and sent to the upper monitor.
If the answer delay is shorter than the system
processing time, then the answer delay time is
the system processing time, if the answer delay
is longer than the system processing time, then
after the system dealing with the data, it waits
until achieving the answer delay time to send the
data to the upper monitor.
5
○
P14.04
Communication
overtime fault
time
0.0 (invalid), 0.1~60.0s
When the function code is set as 0.0, the
communication overtime parameter is invalid.
When the function code is set as non-zero, if the
interval time between two communications
exceeds the communication overtime, the
system will report "485 communication faults"
0.0s
○
P14.05
Transmission
error
processing
1: No alarm and continue running
2: No alarm and stop as per the stop mode (only
under communication control mode)
3: No alarm and stop as per the stop mode
(under all control modes)
0
○
P14.06
Communication
0x000~0x111
Ones place: Responding to write operations
0x000
○
