SD1 Series Inverters Function Parameters
-99-
Function
code
Name Description Default Modify
P17.08 Motor power
Display the power of the motor.
Setting range: -300.0%~300.0%
(the rated current of the motor)
●
P17.09 Output torque
Display the output torque of the inverter.
Range: -250.0~250.0%
●
P17.10
Motor
frequency
evaluation
Evaluate the motor rotor frequency on open loop
vector
Range: 0.00~P00.03
●
P17.11
DC bus voltage
Display the DC bus voltage of the inverter
Range: 0.0~2000.0V
●
P17.12
Switch input
terminals state
Display the Switch input terminals state of the
inverter
Range: 0000~00FF
●
P17.13
Switch output
terminals state
Display the Switch output terminals state of the
inverter
Range: 0000~000F
●
P17.14
Digital
adjustment
Display the adjustment through the keypad of the
inverter.
Range: 0.00Hz~P00.03
●
P17.15
Torque
reference
Display the torque reference, the percentage to
the current rated torque of the motor.
Setting range: -300.0%~300.0%
(of the rated motor current)
●
P17.16 Linear speed
Display the linear speed of the inverter.
Range: 0~65535
●
P17.18 Counting value
Display counting number of the inverter.
Range: 0~65535
●
P17.19
AI1 input
voltage
Display analog AI1 input signal
Range: 0.00~10.00V
●
P17.20
AI2 input
voltage
Display analog AI2 input signal
Range: 0.00~10.00V
●
P17.21
AI3 input
voltage
Display analog AI2 input signal
Range: -10.00~10.00V
●
P17.22
HDI input
frequency
Display HDI input frequency
Range: 0.000~50.000kHz
●
P17.23
PID reference
value
Display PID reference value
Range: -100.0~100.0%
●
