SD1 Series Inverters Function Parameters
-73-
Function
code
Name Description Default Modify
15: Overheat of rectifier module (OH1)
16: Overheat fault of inverter module (OH2)
17: External fault (EF)
18: 485 communication faults (CE)
19: Current detection fault (ItE)
20: Motor autotune fault (tE)
21: EEPROM operation fault (EEP)
22: PID feedback offline fault (PIDE)
23: Braking unit fault (bCE)
24: Running time reached (END)
25: Electronic overload (OL3)
26: Panel communication error (PCE)
27: Parameter upload error (UPE)
28: Parameter download error (DNE)
29~31: Reserved
32: To-earth short circuit fault 1 (ETH1)
33: To-earth short circuit fault 2 (ETH2)
34: Speed deviation fault (dEu)
35: Maladjustment (STO)
36: Underload fault (LL)
37: Safe torque off (STO)
38: Channel 1 is abnormal (STL1)
39: Channel 2 is abnormal (STL2)
40: Channel 1 and channel
2 become abnormal
simultaneously (STL3)
41: Safety code FLASH CRC check fault (CRCE)
P07.33
Reference frequency of present fault
0.00Hz
●
P07.34
Ramps reference frequency of present fault
0.00Hz
●
P07.35
Output voltage of present fault
0V
●
P07.36
Output current of present fault
0.0A
●
P07.37
Bus voltage of present fault
0.0V
●
P07.38
Max. temperature of present fault
0.0°C
●
P07.39
Input terminals state of present fault
0
●
P07.40
Output terminals state of present fault
0
●
P07.41
Running frequency of the last fault
0.00Hz
●
P07.42
Ramps reference frequency of the last fault
0.00Hz
●
P07.43
Output voltage of the last fault
0V
●
P07.44
Output current of the last fault
0.0A
●
