SD1 Series Inverters Function Parameters
-87-
Function
code
Name Description Default Modify
the reference and the feedback changes, it
needs more time to offset the impact of
continuous working and
the integration will
change with the trend.
1: Stop integral adjustment when the frequency
reaches the upper/lower
limit. If the integration
keeps stable, and the trend between the
reference and the feedback changes, the
integration will change with the trend quickly.
Tens place:
0: The same with the main reference
direction; if
the output of PID adjustment is different from the
current running direction, the internal will output
0 forcedly.
1: Opposite to the main reference direction
Hundreds place:
0: Limit as per the maximum frequency
1: Limit as per A frequency
Thousands place:
0:
A+B frequency, main reference A frequency
source buffering ACC/DEC is invalid.
1: M
ain reference A frequency source buffering
ACC/DEC is valid, and the ACC/DEC is
determined by P08.04.
P09.15
PID command
acceleration/
deceleration
time
0.0~1000.0s 0.0s ○
P09.16
PID output filter
time
0.000~10.000s 0.000s ○
P09.17
Low frequency
proportional
gain (Kp)
0.00~100.00 1.00 ○
P09.18
Low frequency
integral time
(Ti)
0.00~10.00s 0.10s ○
P09.19
Low frequency
differential time
(Td)
0.00~10.00s 0.00s ○
