SD1 Series Inverters STO Function DescriptionOptional Peripheral Accessories
-165-
Item
□
Ensure that the drive can be run or stopped randomly during commissioning.
□
Stop the drive (if it is running), disconnect the input power supply, and isolate
the drive from the power cable through the switch.
□
Check the STO circuit connection according to the circuit diagram.
□
Check whether the shielding layer of the STO input cable is connected to the
+24 V reference ground COM.
□
Connect the power supply.
□
Test the STO function as follows the motor stops running:
 If the drive is running, send a stop command to it and wait until the shaft
of the motor stops rotating.
 Activate the STO circuit and send a start command to the drive. Ensure
that the motor does not start.

Deactivate the STO circuit.
□
Restart the drive, and check whether the motor is running properly.
□
Test the STO function as follows when the motor is running:
 Start the drive. Ensure that the motor is running properly.
 Activate the STO circuit.
 The drive reports an STO fault. Ensure that the motor coasts to stop
rotating.

Deactivate the STO circuit.
□
Restart the drive, and check whether the motor is running properly.
