SD1 Series Inverters Function Parameters
-47-
Function
code
Name Description Default Modify
P02.04
Rated voltage
of async-motor
0~1200V
Depend
on
model
◎
P02.05
Rated current
of async-motor
0.8~6000.0A
Depend
on
model
◎
P02.06
Stator resistor
of async-motor
0.001~65.535Ω
Depend
on
model
○
P02.07
Rotor resistor
of async-motor
0.001~65.535Ω
Depend
on
model
○
P02.08
Leakage
inductance of
async-motor
0.1~6553.5mH
Depend
on
model
○
P02.09
Mutual
inductance of
async-motor
0.1~6553.5mH
Depend
on
model
○
P02.10
Non-load
current of
async-motor
0.1~6553.5A
Depend
on
model
○
P02.11
Magnetic
saturation
coefficient 1 for
iron core of
async-motor 1
0.0~100.0% 80.0% ◎
P02.12
Magnetic
saturation
coefficient 2 for
iron core of
async-motor 1
0.0~100.0% 68.0% ◎
P02.13
Magnetic
saturation
coefficient 3 for
iron core of
async-motor 1
0.0~100.0% 57.0% ◎
P02.14
Magnetic
saturation
0.0~100.0% 40.0% ◎
