SD1 Series Inverters Function Parameters
-58-
Function
code
Name Description Default Modify
P05.04
S4 terminal
function
selection
7: Fault reset
8: Operation pause
9: External fault input
10: Increasing frequency setting (UP)
11: Decreasing frequency setting (DOWN)
12: Cancel the frequency change setting
13: Shift between A setting and B setting
14:
Shift between combination setting and A
setting
15:
Shift between combination setting and B
setting
16: Preset speed terminal 1
17: Preset speed terminal 2
18: Preset speed terminal 3
19: Preset speed terminal 4
20: Preset speed pause
21: ACC/DEC time selection terminal 1
22: ACC/DEC time selection terminal 2
23: Simple PLC stop reset
24: Simple PLC pause
25: PID control pause
26: Wobbling frequency pause (stop at present
frequency)
27: Wobbling frequency reset
(return to center
frequency)
28: Counter reset
29: Torque control prohibition
30: ACC/DEC prohibition
31: Counter trigger
32: Reserved
33:
Cancel the frequency change setting
temporarily
34: DC brake
35: Reserved
36: Shift the command to keypad
37: Shift the command to terminals
38: Shift the command to communication
39: Pre-magnetized command
0 ◎
P05.05
S5 terminal
function
selection
0 ◎
P05.06
S6 terminal
function
selection
0 ◎
P05.07
S7 terminal
function
selection
0 ◎
P05.08
S8 terminal
function
selection
0 ◎
P05.09
HDI terminal
function
selection
0 ◎
