IMT 5020 Parts & Specifications

Chapter 5 General Reference 109
FREQUENCY
ITEM KEY INSPECTION DESCRIPTION STATUS
(S,R,X,NA)
76 • Load holding valve(s)
77 • Outrigger or auxiliary control valve(s)
78 • Other
79 • Other
Q 80 Cylinders Hydraulic cylinders for drifting, rod seal leakage and leakage at welds.
Rods for nicks, scores and dents. Case for damage. Case and rod
ends for damage and abnormal wear.
81 • Outrigger cylinder(s)
82 • Inner boom cylinder(s)
83 • Outer boom cylinder(s)
84 • Extension cylinder(s)
85 • Rotation cylinder(s)
86 • Jib lift cylinder(s)
87 • Jib extension cylinder(s)
88 • Other
Q 89 Winch Winch, sheaves and drums for damage, abnormal wear, abrasions
and other irregularities.
Q 90 Hyd Filters Hydraulic filters for replacement per maintenance schedule.
A 91 Daily All daily inspection items.
A 92 Monthly All monthly inspection items.
A 93 Quarterly All quarterly inspection items.
A 94 Hyd Sys Hydraulic fluid change per maintenance schedule.
A 95 Controls Control valve calibration for correct pressure & relief valve settings.
A 96 Valves Safety valve calibration for correct pressure & relief valve settings.
A 97 Valves Valves for failure to maintain correct settings.
A 98 Rotation Sys Rotation drive system for proper backlash clearance & abnormal wear,
deformation and cracks.
A 99 Lubrication Gear oil change in rotation drive system per maintenance schedule.
A 100 Hardware Check tightness of all fasteners and bolts.
A 101 Wear Pads Wear pads for excessive wear.
A 102 Loadline Loadline for proper attachment to drum.

IMT 5020 Specifications

General

Brand	IMT
Model	5020
Category	Construction Equipment
Language	English
