IMT 5020 - 1-7: CRANE CAPACITY AND LOAD LIMITS

Chapter 2 Specifications 11
Geometric Configuration, 5020
20.8"
(52.9 cm)
12.0"
(30.2 cm)
16.7"
(42.4 cm)
8.37" (21.3 cm)
35.0"
(88.9 cm)
18.61"
(47.3 cm)
17.0" (43.2 cm) 22.0" (55.9 cm)
20.0" (50.8 cm)
13'-1"
(3.99 m)
18'-0"
(5.49 m)
20'-0"
(6.10 m)
21'-11"
(6.68 m)
20'-1" (6.12 m)
18'-1" (5.51 m)
16'-1" (4.90 m)
11'-1" (3.38 m)
3'-11"
(1.19 m)
3'-7"
(1.09 m)
3'-3"
(1.0 m)
2'-5"
(0.74 m)
