Chapter 3 Crane Reference 15
Recommended Spare Parts List
This spare parts list does not necessarily indicate that the items can be expected to fail in the
course of a year. It is intended to provide the user with a stock of parts sufficient to keep the unit
operating with the minimal down-time waiting for parts. There may be parts failures not covered
by this list. Parts not listed are considered as not being Critical or Normal Wear items during the
first year of operations and you need to contact the distributor or manufacturer for availability.
ASSEMBLY DESCRIPTION
IMT PART # NAME QUANTITY
BASE ASSEMBLY (41714695)
73051919 HYDRAULIC MOTOR 1
LOWER BOOM ASSEMBLY (41717147)
3C210010 LOWER CYLINDER 1
60120124 WEAR PAD 4
72060293 CAP SCREW 5/16-24X1
HHGR5
8
LOWER CYLINDER (3C210010)
4G035980 ROD ASSEMBLY 1
6HD45022 HEAD 1
6ID45143 PISTON 1
9D181823 SEAL KIT 1
77041561 PRESSURE SWITCH 1
73540052 COUNTERBALANCE VALVE 1
EXTENSION BOOM ASSEMBLY (41717145)
3B210013 EXTENSION CYLINDER 1
60030189 WEAR PAD 1
60030134 SHEAVE 2
EXTENSION BOOM ASSEMBLY, 20' WITH
FLIPSHEAVE (41714691)
3B313960 EXTENSION CYLINDER 1
60030189 WEAR PAD 1
EXTENSION CYLINDER (3B210013)
73054999 COUNTERBALANCE VALVE 1
9D101220 SEAL KIT 1
WINCH / CABLE / HOOK KIT (31714696) & WINCH /
CABLE / HOOK KIT W/ FLIPSHEAVE (31714697)
73051940 HYDRAULIC MOTOR 1
70580143 CABLE ASSEMBLY 1
